SharpenImage

Enhances contrast of an image so that it appears sharper.

Name	Type	Range	Description
inImage	Image		Input image
inContrastFactor	Real	0.0 -	Value representing the strength of the contrast enhancement
inKernel	KernelShape		Kernel shape
inRadiusX	Integer	0 -	Nearly half of the kernel's width (2*R+1)
inRadiusY	Integer *	0 -	Nearly half of the kernel's height (2*R+1), or same as inRadiusX
outImage	Image		Output image

Applications

Use this filter only to improve human perception, not to preprocess an image for analysis.

Description

This filter increases the contrast of the image by multiplying by inContrastFactor the difference between a pixel value and its corresponding pixel value in the smoothed input image:

\[ \begin{aligned} outImage[i,j] &= inImage[i,j] + inContrastFactor \times (inImage[i,j] - smoothedImage[i,j]) \\ \end{aligned} \]

Examples

SharpenImage run on example image with inContrastFactor = 2.

Hardware Acceleration

This operation supports automatic parallelization for multicore and multiprocessor systems.

Complexity Level

This filter is available on Basic Complexity Level.
